P2.976 P3.91 P4.81 Indoor Outdoor Rental Stage LED Screen

Basic Info.

Model NO.	P4.81 LED Screen
Pixel Configuration	1R, 1G, 1B
Display Function	Video Display, Image & Text Display, Text Display, Market Display
Average Power Consumption	350W / m²
Pixel Density	43222 Pixels/Square Meter
Scanning Mode	1/13 Scan
Display Type	LED Video Display
Application	Stage Performance
Certification	CE, RoHS, CCC, ISO, SGS
Cabinet Material	Steel/Die Casting
Life Time	100, 000hours
Warranty	2 Years
Cabinet Size	500mm*1000mm
View Distance	3--200m
Exchange Frame Speed	>150frames Per Second
Refresh Rate	1920Hz/3840Hz
Brightness	≥6000CD/Square Meter
Transport Package	Wooden Case Packing
Specification	500mm*1000mm
Trademark	CHEE CHUANG
Origin	China, Guangzhou
HS Code	8528591090
Production Capacity	3000 Square Meters / Month

Packaging & Delivery

Package Size 110.00cm * 90.00cm * 75.00cm Package Gross Weight 60.000kg

Product Description

High Quality Indoor Outdoor led screen P2.976 / P3.91 / P4.81 Rental stage LED Screen for Events

Technical Parameters

Pitch Size	4.81mm
Module Size	250*250mm
Module Pixel(dots)	52dots*52dots
Pixel Configuration	1 Red, 1 Green, 1 Blue SMD 3-in-1
LED chip	Sanan
Color scale	65536degree/16777216colors
Pixel density	43222pixels/square meter
View angle(H/V)	≥140/140degree
Brightness	≥6000cd/square meter
Brightness adjustment	64 level automatic or manual
View distance	3--200m
Power consumption	100-1200W/square meter
Net weight	30kg/square meter
Operating temperature	-25°C~+60°C
Operating humidity	10%-95%RH
Life time	≥100,000hours
Out of control dot	≤1/10,000
Whole Display Flatness	≤1mm Juncture
Exchange frame speed	>150frames per second
Refresh frame frequency	1920Hz-3840Hz
Control distance	120m (without repeater), single mode fiber:20km, multi mode fiber: 500m
Power	110V/220V±15% 50Hz
Operating system	Windows series
Drive mode	constant current driving, 1/13 scan
Display mode	VGA640X480-VGA1600X1024
Protection Level	IP65
Maintenance way	Rear access
Accepting signal	PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI

Other products:Indoor fixed LED screen: P1.53,P1.875,P2,P2.5, P3, P4, P5, P6, P8, P10Indoor rental LED screen: P2.5,P2.976,P3, P3.91, P4, P4.8, P4.81, P5, P6Outdoor fixed LED screen: P2.5, P3, P4, P5, P6, P6.67,P8, P10Outdoor rental LED screen:P3, P3.91, P4, P4.8, P4.81, P5, P6, P8, P10Small pitch LED screen: P1.25, P1.53Front service maintenance LED screen: P6.67, P8, P10Stadium perimeter LED screen: P4, P5, P6, P8, P10LED poster player: P1.875, P2.5, P3, P4, P5, P6, P8, P10
Company Information

Packing & Shipping

Payment terms: By T/T in advance, 30% deposit and the balance 70% before shipment.

Delivery time:15-20days

Warranty time:2 years,offer the free spare parts(module & power supply) in advance.After guarantee term,still supply spare parts with charging only materials cost.

Packing:Standard wooden case packing free,flight case packing
